TORO B-203/C

Lifter – Low-level loading

Maximum lifting height (Forks up) 6.30 m I 20 ft 8 in

Maximum lifting height (Forks down) 6.05 m I 19 ft 10 in

Maximum Load 220 kg I 485 lb

Height stowed 1.66 m I 5 ft 5.5 in

Load height 28 cm I 11 in

2-in-1 design lifter Front or rear legs (included)

Leveler screw-jacks On side stabilizers and legs

Side stabilizer arms Included

Telescopic legs Included

Safety Systems IPB System (Internal Pendulum Brake) + MSU System

Double-handled Brake Winch

Transport Equipped with 12 wheels

Folding handgrip with wheels Yes. For horizontal transportation and loading in vehicles

Stowed dimensions 88 x 65 x 166 cm I 2 ft 10.5 in x 2 ft 1.5 in x 5 ft 5.5 in

Material Aluminum (alloy EN AW 6082-T6) & Steel

Complies with Standards 2006/42/EC

Net Weight 139 kg I 306 lbs

Sections 5 – Profile dimension (width): 135 mm I 5.31 in
