• Acceptable spacer hollow profiles from 6 to 32 mm. (from 0,23″ to 1,26″) (optional, several sizes) H=6,5 mm (H=0,25″)
• Minimum spacer frame dimensions (rectangular reference) 100 mm x 150 mm (3,93″ x 5,9″)
• Maximum spacer frame dimensions (rectangular reference) 1600 mm x 2000 mm (63″x 78,7″) one piece (no limits with several pieces)
• Shapes allowed infinite
• Edge bending from 0° to 155°
• Radius of curvature allowed with optional “curved shapes”….from 100 to 4000 mm (from 3,93″ to 157,5″) (profiles thickness from 6 to 18 mm) (from 0,23″ to 0,7″) from 200 to 4000 mm (from 7,87″ to 157,5″) (profiles thickness from 20 to 32 mm) (from 0,78″ to 1,26”)

Productivity:

• spacer frame in aluminium and different plastics 150÷160 spacer frames/hour
• spacer frame in carbon steel ~ 100 spacer frames/hour
• spacer frame in stainless steel 70÷80 spacer frames/hour
• Chromatec with thicknesses 10 12 14 15 16 18 20 22 24
